Zoomable Architecture

When presenting the architecture of a system to an audience one typically will modify the level of detail to fit the audience’s leaning objectives. Sometimes you will find a high level picture of the main architectural components is sufficient and the audience would be overwhelmed with any more detail. Other times you may be presenting to a highly technical team who want to know the details of how specific components work, in these cases you’ll show much more detail. And in other cases a medium level of detail is just right.

To serve these different levels of abstraction, architects typically draw lots of diagrams or just draw one huge super detailed diagram which doesn’t show well when trying to convey the high level architecture. The problem with lots of diagrams is that you are repeating your work over and over as your models change, since every diagram may need to be updated to accommodate a system change. I’ve always found this especially annoying, just the inefficiency of repeated modeling at different levels. I began searching for tools that allowed for a more holistic approach to system modeling. What I really wanted was a single model that would change in the level of detail as you zoomed into it, like Google Maps but for non-spatial maps.

One way to do that is to use shapefiles, where each layer represents a different level of detail (zoom level). In this way you can draw the big picture at the outermost zoom layer, and then add more details on the medium layer, and so on with as many layers as needed. This proof of concept uses 4 layers that can be zoomed into. I used Open Jump to build the layers and associated styles. The next step is to host the shapefiles on a map server so your model can be served up via a web server. This means it can be embedded in an HTML web page for example. This makes your models more interactive potentially and easier to digest.


If you’re building software services and want to achieve a stateless architecture you are probably interested in a distributed cache. This is a very popular pattern used in modern high scale systems.

Stateless Defined

When I stay stateless architecture what I mean is an architecture that allows homogeneous units to be added or removed from the system without negatively affecting current sessions.

Why Stateless?

A system that is not stateless will generally use “sticky sessions” where a load balancer maps a given session to a given machine to serve requests for the life of the session. The problem with sticky sessions is that all sessions tied to a given machine will need to be “bled off” before the machine can be taken down for maintenance. Further in the an unexpected machine failure all sessions will be lost, resulting in a potentially unacceptable situation for users of those sessions.

How Distributed Cache Helps

Moving to a stateless architecture means shifting the location of session state off the individual scale out machines (web or application servers) and into a central session state store. This store needs to be durable and should be run in a high availability mode for any critical systems. By moving the state to a central location, web or application servers can scale up or down and turn on or off without any warning since there should be no impact to users if their requests are handled by multiple machines. This means setting up the load balancer to use a different algorithm than sticky sessions, ideally performance based or simply round robin. When state is needed by a machine it is requested from the central cache. Updates and inserts are written to the central cache, making the data available to all machines that may service future requests for a given session.

Distributed Cache without a Session

Distributed caches are great for session state but can also be used in other contexts, like a user context, or a tenant context. For example a mutli-tenant application may want to cache the settings for tenants but these are not necessarily tied to any individual session. You may also want to cache settings about a user that don’t need to be stored in a session context. So you’ll find there are several levels of granularity to cache things at and its not always the session level. You’ll need to think about all these things when designing your distributed cache strategy.

Conclusion
